Core Web Vitals Monitor for Magento 2

What you get

Magento 2 Core Web Vitals

Panth_CoreWebVitals collects Core Web Vitals (LCP, FID, INP and CLS) from real visitors of a Magento 2 storefront. When the module is enabled it renders an inline JavaScript snippet on every frontend page that registers PerformanceObserver listeners in the browser, rates each collected value, and optionally forwards the values to Google Analytics 4 and to a custom beacon endpoint. It also lets the administrator output resource hint link tags (dns-prefetch, preconnect, prefetch) and adds performance related HTTP headers (Server-Timing, X-DNS-Prefetch-Control, Link) to the response.

The module is aimed at merchants and developers who want field measurements of their store's Core Web Vitals without adding a third party library. It uses the standard head.additional block and before.body.end container and contains no theme specific code, so it works on both Hyva and Luma themes.

Product page: kishansavaliya.com/magento-2-corewebvitals.html

Features

• Collects LCP using the largest-contentful-paint PerformanceObserver entry type (the last reported entry is used).
• Collects FID using the first-input entry type.
• Collects INP using the event entry type with a durationThreshold of 16 ms; only entries with an interaction id count, and the worst interaction duration seen so far is kept.
• Collects CLS using the layout-shift entry type, ignoring shifts that follow recent user input and aggregating shifts into session windows (gap under 1 s, window under 5 s).
• Rates each value as good, needs-improvement or poor using fixed thresholds (LCP 2500/4000 ms, FID 100/300 ms, INP 200/500 ms, CLS 0.1/0.25).
• Sends each metric to GA4 through gtag() when gtag is present on the page, with an optional send_to measurement ID.
• Sends the final value of each metric as a JSON document to a custom endpoint through navigator.sendBeacon when the page is hidden or left (again only if the value changed afterwards).
• Dispatches a DOM CustomEvent (coreWebVitals:lcp, coreWebVitals:fid, coreWebVitals:inp, coreWebVitals:cls) on window for every collected metric.
• Debug mode logs every metric to the browser console, exposes window.coreWebVitalsMetrics, and prints a final summary when the page becomes hidden.
• Outputs <link rel="dns-prefetch">, <link rel="preconnect" crossorigin> and <link rel="prefetch"> tags from admin configured lists.
• Adds a Server-Timing header with the PHP execution time, an X-DNS-Prefetch-Control: on header when DNS prefetch domains are configured, and a Link: <origin>; rel=preconnect; crossorigin header for each preconnect domain.
• Per metric enable switches; all settings are scoped to default, website and store view.
• Unit tests for the helper, plugin and observer under Test/Unit.

Usage

Page output. With the module enabled, the frontend default.xml layout adds two blocks:

• panth.corewebvitals.resource.hints (template resource-hints.phtml) in the head.additional block. It prints the dns-prefetch, preconnect and prefetch link tags, if any are configured, inside <head>.
• panth.corewebvitals.monitor (template core-web-vitals.phtml) in the before.body.end container. It prints an inline <script> that reads a JSON configuration object built by Helper\Data::getConfigJson() and registers the PerformanceObserver listeners. The script exits immediately if PerformanceObserver is not available in the browser.

Metric collection. Each metric is reported with a name (LCP, FID, INP, CLS), a numeric value (milliseconds, or a unitless score for CLS), a rating, an id, a delta and the observed entries. Values are rated against the thresholds published for Core Web Vitals (see web.dev), with the "good" boundary of each metric replaced by the configured target.

Reporting. When "Send Metrics to Analytics" is Yes:

• If window.gtag exists, the script calls gtag('event', <metric name>, {...}) with event_category: 'Web Vitals', value (CLS multiplied by 1000 and rounded; other metrics rounded to whole milliseconds), event_label (the metric id), metric_rating and non_interaction: true. When a GA4 Measurement ID is configured it is added as send_to.
• If a beacon URL is available, the script posts a JSON body with the fields name, value, rating, id, delta, page (path and query string) and timestamp using navigator.sendBeacon. The URL comes from "Custom Beacon Endpoint URL"; if that is blank the script falls back to window.panthCoreWebVitalsEndpoint when a site defines it.

In addition, every metric dispatches window.dispatchEvent(new CustomEvent('coreWebVitals:<metric>', { detail })), so other scripts can listen with, for example, window.addEventListener('coreWebVitals:lcp', function (e) { console.log(e.detail); }).

Response headers. The plugin Plugin\AddPerformanceHeaders runs before Magento\Framework\App\Response\Http::sendResponse() and, when the module is enabled, sets:

• Server-Timing: app;desc="PHP Execution";dur=<milliseconds since REQUEST_TIME_FLOAT> (appended to an existing Server-Timing value)
• X-DNS-Prefetch-Control: on when at least one DNS prefetch domain is configured
• Link: <https://domain>; rel=preconnect; crossorigin, ... for the configured preconnect domains, appended to an existing Link header

The plugin is declared in etc/frontend/di.xml, so it only applies to storefront responses, not to the admin, REST, SOAP or GraphQL areas.

The module has no admin report pages, no scheduled cron jobs and no console commands. Collected metrics are not stored in Magento; they only exist in the browser and in whatever analytics destination is configured.

Documentation

USER_GUIDE.md is written for store administrators and covers installation, verifying that the module is active, every configuration field, what each metric means, resource hints, the performance HTTP headers, integrating with GA4 or a custom endpoint, and troubleshooting.

Changelog

See CHANGELOG.md.

Compatibility

Composer constraints on Magento packages: magento/framework ^103.0, magento/module-store ^101.0, magento/module-config ^101.0, magento/module-backend ^102.0.

Requirements

• Magento Open Source or Adobe Commerce 2.4.4 to 2.4.9.
• PHP 8.1, 8.2, 8.3 or 8.4.
• mage2kishan/module-core ^1.0 (module Panth_Core), which provides the "Panth Extensions" admin menu that this module attaches to. Composer installs it automatically.
• No other packages are required or suggested by composer.json.

Installation

composer require mage2kishan/module-corewebvitals
bin/magento module:enable Panth_Core Panth_CoreWebVitals
bin/magento setup:upgrade
bin/magento setup:di:compile
bin/magento cache:flush

setup:di:compile is only needed when Magento runs in production mode. The module ships no files under view/*/web, so setup:static-content:deploy is not required for it.

Check that the module is active:

bin/magento module:status Panth_CoreWebVitals

Configuration

Admin path: Stores > Configuration > Panth Extensions > Core Web Vitals (section id panth_corewebvitals). All fields can be set at default, website and store view scope. The module is disabled by default; nothing is rendered and no headers are added until "Enable Module" is set to Yes.

General Settings

Config paths: panth_corewebvitals/general/enabled, panth_corewebvitals/general/debug_mode, panth_corewebvitals/general/real_user_monitoring, panth_corewebvitals/general/endpoint_url, panth_corewebvitals/general/ga4_measurement_id.

LCP (Largest Contentful Paint) Monitoring

Config paths: panth_corewebvitals/lcp/enabled, panth_corewebvitals/lcp/target_lcp.

FID / INP (Interaction Responsiveness) Monitoring

Config paths: panth_corewebvitals/fid/enabled, panth_corewebvitals/fid/target_fid, panth_corewebvitals/fid/target_inp.

CLS (Cumulative Layout Shift) Monitoring

Config paths: panth_corewebvitals/cls/enabled, panth_corewebvitals/cls/target_cls.

Resource Hints

Config paths: panth_corewebvitals/resource_hints/dns_prefetch, panth_corewebvitals/resource_hints/preconnect, panth_corewebvitals/resource_hints/prefetch.

Blank lines and surrounding whitespace in the textarea fields are ignored.

Uninstallation

bin/magento module:disable Panth_CoreWebVitals
composer remove mage2kishan/module-corewebvitals
bin/magento setup:upgrade
bin/magento setup:di:compile
bin/magento cache:flush

No database tables are created by the module, so nothing needs to be dropped. Saved configuration values under panth_corewebvitals/* remain in core_config_data and can be deleted manually if wanted. Remove Panth_Core only if no other Panth module depends on it.

License

Free and open source under the MIT License. See LICENSE.

Developer Notes

• Module name: Panth_CoreWebVitals
• Composer package: mage2kishan/module-corewebvitals (version 1.0.11)
• PHP namespace: Panth\CoreWebVitals
• Load sequence: after Magento_Store, Magento_Config and Panth_Core
• Key classes:
• Helper\Data reads all configuration values at store scope (the current store unless a store id is passed) and builds the JSON configuration for the script (getConfigJson()).
• Block\CoreWebVitals exposes isEnabled() and getConfigJson() to core-web-vitals.phtml.
• Block\ResourceHints exposes isEnabled(), getDnsPrefetchDomains(), getPreconnectDomains() and getPrefetchUrls() to resource-hints.phtml.
• Plugin\AddPerformanceHeaders::beforeSendResponse() adds the response headers (plugin name panth_corewebvitals_performance_headers, sort order 10).
• Extension points: the coreWebVitals:* DOM events, the window.panthCoreWebVitalsEndpoint global as a fallback beacon URL, and the two named layout blocks, which can be moved or removed in a theme's default.xml.
• ACL resources: Panth_CoreWebVitals::corewebvitals ("Core Web Vitals") and Panth_CoreWebVitals::config ("Configuration"), both under Magento_Config::config.
• Admin menu: "Core Web Vitals" > "Configuration" under the "Panth Extensions" menu provided by Panth_Core, linking to the configuration section.
• Database: the module ships no db_schema.xml and creates no tables.
• Translations: i18n/en_US.csv.
