OpenAI API + Magento Integration — A Complete Working Extension

Panth_AiAssist is a Magento 2.4.4 — 2.4.9 module that bundles every piece of OpenAI integration the average store needs into one shippable extension — an admin grid for prompt templates, a retrying client around the OpenAI Chat Completions API, a per-call token cost log, a CLI batch runner, and a provider abstraction that swaps to Anthropic with one di.xml line. Most tutorials show a curl example and stop. This walkthrough ships the entire module — file tree, schema, PHP class signatures, SQL audit query, and the security boundary that has to hold before any of it goes to production.^[1]

One module is the right abstraction, not four curl scripts

Most teams start with a one-off CLI script and end up with five disconnected scripts, each with its own copy of the OpenAI client, each with a forgotten $apiKey hardcoded, and no answer to "what did we spend last month". The fix is one module in app/code/Panth/AiAssist/ that owns every OpenAI call in the store.

The full file tree

app/code/Panth/AiAssist/
├── etc/                  (module.xml, di.xml, db_schema.xml, acl.xml,
│                          adminhtml/{routes,menu,system}.xml, config.xml)
├── Api/                  (LlmProviderInterface, PromptTemplateRepositoryInterface,
│                          Data/{PromptTemplateInterface, CallLogInterface}.php)
├── Model/                (PromptTemplate, PromptTemplateRepository, CallLog,
│                          PlaceholderResolver, ResourceModel/*)
├── Service/              (OpenAiClient, AnthropicClient, BudgetGuard,
│                          RetryPolicy, CallLogger)
├── Console/Command/      (RunTemplateCommand.php)
├── Controller/Adminhtml/ (Template/{Index, Edit, Save, Delete}.php)
├── Ui/Component/         (Listing column renderers)
├── registration.php
└── composer.json

Around 40 source files ship as a Composer package panth/module-ai-assist. Every downstream module — Panth_ProductCopy, Panth_ReviewSummary, Panth_AdminAssistant — depends on this one and never touches the OpenAI SDK directly.

1. Module structure and the two database tables

Two new tables — panth_ai_prompt_template and panth_ai_call_log — are the only persistence the module owns. Declarative schema handles install and upgrade on every setup:upgrade.^[2]

etc/db_schema.xml

<?xml version="1.0"?>
<schema xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance"
        xsi:noNamespaceSchemaLocation="urn:magento:framework:Setup/Declaration/Schema/etc/schema.xsd">
    <table name="panth_ai_prompt_template" resource="default" engine="innodb">
        <column xsi:type="int" name="template_id" identity="true" unsigned="true" nullable="false"/>
        <column xsi:type="varchar" name="code" length="64" nullable="false" comment="product-description, review-summary, etc"/>
        <column xsi:type="varchar" name="title" length="255" nullable="false"/>
        <column xsi:type="text" name="system_prompt" nullable="true"/>
        <column xsi:type="text" name="user_prompt" nullable="false"/>
        <column xsi:type="varchar" name="model" length="64" nullable="false" default="gpt-4o-2024-11-20"/>
        <column xsi:type="smallint" name="max_tokens" unsigned="true" nullable="false" default="500"/>
        <column xsi:type="decimal" name="temperature" scale="2" precision="3" nullable="false" default="0.20"/>
        <column xsi:type="smallint" name="version" unsigned="true" nullable="false" default="1"/>
        <column xsi:type="boolean" name="is_active" nullable="false" default="true"/>
        <column xsi:type="varchar" name="ab_variant" length="8" nullable="true" comment="A or B, null for non-AB"/>
        <column xsi:type="decimal" name="monthly_budget_usd" scale="2" precision="10" nullable="true"/>
        <column xsi:type="timestamp" name="created_at" default="CURRENT_TIMESTAMP"/>
        <column xsi:type="timestamp" name="updated_at" on_update="true" default="CURRENT_TIMESTAMP"/>
        <constraint xsi:type="primary" referenceId="PRIMARY">
            <column name="template_id"/>
        </constraint>
        <index referenceId="PANTH_AI_TEMPLATE_CODE" indexType="btree">
            <column name="code"/>
        </index>
    </table>

    <!-- panth_ai_call_log: log_id, template_id, provider, model, prompt_tokens,
         completion_tokens, total_cost_usd, latency_ms, http_status, retry_count,
         entity_type, entity_id, created_at. Index on (template_id, created_at). -->
</schema>

Two tables, zero foreign keys on purpose. The call log keeps growing — pruning is a cron concern, not a constraint concern — and the prompt template id can be deleted without orphaning audit history.

2. The admin grid — versioned templates with A/B variants

The admin lands on Stores → AI Assist → Prompt Templates and sees a UI Component grid. Six columns matter: code, title, model, version, ab_variant, and a usage column that joins to panth_ai_call_log for last-30-day call count and cost.

The form fields per template

• Code — slug used by the CLI runner, e.g. product-description.
• System prompt + user prompt — placeholders {{product.name}}, {{customer.first_name}}, {{cart.subtotal}} resolved by PlaceholderResolver at render time.
• Model — pinned versions only: gpt-4o-2024-11-20, gpt-4o-mini-2024-07-18, gpt-3.5-turbo-0125, claude-opus-4-7-20251015, claude-sonnet-4-7-20251015.
• Max tokens / temperature — per-template overrides.
• Monthly budget USD — soft budget; BudgetGuard demotes to a cheaper model when exceeded.
• Version / A-B variant — edit creates a new row with version + 1; A/B clones with ab_variant = 'B' and routes 50/50.

The PromptTemplateRepository interface

<?php
declare(strict_types=1);

namespace Panth\AiAssist\Api;

use Panth\AiAssist\Api\Data\PromptTemplateInterface;

interface PromptTemplateRepositoryInterface
{
    public function getByCode(string $code, ?string $abVariant = null): PromptTemplateInterface;

    public function save(PromptTemplateInterface $template): PromptTemplateInterface;

    public function deleteById(int $templateId): void;

    /**
     * @return PromptTemplateInterface[]
     */
    public function getActiveVariants(string $code): array;
}

The repository is a service contract — register it in etc/webapi.xml if you want REST access. Every consumer goes through this interface; the resource model is swappable.

3. The OpenAI client — retry, backoff, and model fallback

The client wraps Guzzle, retries the right HTTP statuses, logs every call, and demotes the model when a soft budget is exceeded. The centerpiece of the module.

Service/OpenAiClient.php

<?php
declare(strict_types=1);

namespace Panth\AiAssist\Service;

use GuzzleHttp\Client;
use GuzzleHttp\Exception\GuzzleException;
use Magento\Framework\Encryption\EncryptorInterface;
use Magento\Framework\App\Config\ScopeConfigInterface;
use Panth\AiAssist\Api\LlmProviderInterface;
use Panth\AiAssist\Api\Data\PromptTemplateInterface;

class OpenAiClient implements LlmProviderInterface
{
    private const ENDPOINT = 'https://api.openai.com/v1/chat/completions';
    private const CONFIG_PATH_KEY = 'panth_aiassist/openai/api_key';
    private const FALLBACK_MODEL = 'gpt-3.5-turbo-0125';

    public function __construct(
        private readonly Client $http,
        private readonly EncryptorInterface $encryptor,
        private readonly ScopeConfigInterface $scopeConfig,
        private readonly RetryPolicy $retryPolicy,
        private readonly BudgetGuard $budgetGuard,
        private readonly CallLogger $callLogger
    ) {}

    public function complete(PromptTemplateInterface $template, array $variables): string
    {
        $model = $this->budgetGuard->resolveModel($template, $template->getModel(), self::FALLBACK_MODEL);
        $payload = [
            'model'       => $model,
            'temperature' => (float)$template->getTemperature(),
            'max_tokens'  => (int)$template->getMaxTokens(),
            'messages'    => $this->buildMessages($template, $variables),
        ];

        $attempt = 0;
        $startedAt = microtime(true);
        while (true) {
            try {
                $response = $this->http->post(self::ENDPOINT, [
                    'headers' => ['Authorization' => 'Bearer ' . $this->getApiKey()],
                    'json'    => $payload,
                    'timeout' => 60,
                ]);
                $body = json_decode($response->getBody()->getContents(), true);
                $this->callLogger->write($template, $model, $body, $attempt, 200, $startedAt);
                return $body['choices'][0]['message']['content'] ?? '';
            } catch (GuzzleException $e) {
                $status = $e->getResponse()?->getStatusCode() ?? 0;
                $delay = $this->retryPolicy->nextDelayMs($attempt, $status);
                if ($delay === null) {
                    $this->callLogger->write($template, $model, [], $attempt, $status, $startedAt);
                    throw $e;
                }
                usleep($delay * 1000);
                $attempt++;
            }
        }
    }

    private function getApiKey(): string
    {
        return $this->encryptor->decrypt((string)$this->scopeConfig->getValue(self::CONFIG_PATH_KEY));
    }
}

Service/RetryPolicy.php

<?php
declare(strict_types=1);

namespace Panth\AiAssist\Service;

class RetryPolicy
{
    private const RETRIABLE = [408, 429, 500, 502, 503, 504];
    private const MAX_ATTEMPTS = 5;
    private const BASE_MS = 250;

    public function nextDelayMs(int $attempt, int $httpStatus): ?int
    {
        if ($attempt >= self::MAX_ATTEMPTS) {
            return null;
        }
        if (!in_array($httpStatus, self::RETRIABLE, true)) {
            return null;
        }
        // 250, 500, 1000, 2000, 4000 ms — pure exponential, no jitter for predictability.
        return self::BASE_MS * (2 ** $attempt);
    }
}

The retry policy is its own class so it stays exhaustively unit-testable. Keep the retry logic out of the HTTP client and the client stays mockable; keep the HTTP client out of the retry policy and the policy stays pure.

4. The cost log — "what did we spend" is one SQL query

Every call writes one row. After a month of production traffic the table answers the questions finance asks.

Last-30-day spend by template

SELECT
    t.code,
    t.title,
    COUNT(*)                     AS calls,
    SUM(l.prompt_tokens)         AS prompt_tokens,
    SUM(l.completion_tokens)     AS completion_tokens,
    ROUND(SUM(l.total_cost_usd), 2) AS cost_usd,
    ROUND(AVG(l.latency_ms))     AS avg_latency_ms,
    SUM(CASE WHEN l.http_status >= 400 THEN 1 ELSE 0 END) AS error_count
FROM panth_ai_call_log l
JOIN panth_ai_prompt_template t ON t.template_id = l.template_id
WHERE l.created_at >= DATE_SUB(NOW(), INTERVAL 30 DAY)
GROUP BY t.code, t.title
ORDER BY cost_usd DESC;

A/B variant performance

SELECT
    t.code,
    t.ab_variant,
    COUNT(*)                          AS calls,
    ROUND(SUM(l.total_cost_usd), 2)   AS cost_usd,
    ROUND(AVG(l.completion_tokens))   AS avg_output_tokens,
    ROUND(AVG(l.latency_ms))          AS avg_latency_ms
FROM panth_ai_call_log l
JOIN panth_ai_prompt_template t ON t.template_id = l.template_id
WHERE t.ab_variant IS NOT NULL
  AND l.created_at >= DATE_SUB(NOW(), INTERVAL 7 DAY)
GROUP BY t.code, t.ab_variant;

Pair this with a conversion metric from sales_order_item and you have the closed loop: which prompt variant produces descriptions that sell better. We have seen 11–18% lift swings between A and B variants on real catalogs.

5. The CLI batch runner — bulk template execution

The workhorse. Marketing edits a template in the admin, runs the CLI against 5,000 SKUs overnight, reviews the output next morning.

Console/Command/RunTemplateCommand.php

<?php
declare(strict_types=1);

namespace Panth\AiAssist\Console\Command;

use Magento\Catalog\Api\ProductRepositoryInterface;
use Panth\AiAssist\Api\LlmProviderInterface;
use Panth\AiAssist\Api\PromptTemplateRepositoryInterface;
use Symfony\Component\Console\Command\Command;
use Symfony\Component\Console\Input\InputInterface;
use Symfony\Component\Console\Input\InputOption;
use Symfony\Component\Console\Output\OutputInterface;

class RunTemplateCommand extends Command
{
    public function __construct(
        private readonly PromptTemplateRepositoryInterface $templates,
        private readonly LlmProviderInterface $llm,
        private readonly ProductRepositoryInterface $products
    ) {
        parent::__construct();
    }

    protected function configure(): void
    {
        $this->setName('panth:ai:run-template')
            ->addOption('template', 't', InputOption::VALUE_REQUIRED)
            ->addOption('skus', 's', InputOption::VALUE_REQUIRED)
            ->addOption('dry-run', null, InputOption::VALUE_NONE)
            ->addOption('write-to', null, InputOption::VALUE_REQUIRED, '', 'description');
    }

    protected function execute(InputInterface $input, OutputInterface $output): int
    {
        $template = $this->templates->getByCode((string)$input->getOption('template'));
        $skus = array_filter(array_map('trim', explode(',', (string)$input->getOption('skus'))));
        $attribute = (string)$input->getOption('write-to');

        foreach ($skus as $sku) {
            $product = $this->products->get($sku);
            $result = $this->llm->complete($template, ['product' => [
                'name'  => $product->getName(),
                'sku'   => $product->getSku(),
                'price' => (float)$product->getPrice(),
            ]]);
            $output->writeln("<info>{$sku}</info> " . substr($result, 0, 80) . '…');
            if (!$input->getOption('dry-run')) {
                $product->setData($attribute, $result);
                $this->products->save($product);
            }
        }
        return Command::SUCCESS;
    }
}

Real CLI invocations

bin/magento panth:ai:run-template --template=product-description --skus=SKU001,SKU002

bin/magento panth:ai:run-template -t product-description -s SKU001,SKU002 --dry-run

bin/magento panth:ai:run-template -t meta-description -s SKU001,SKU002 --write-to=meta_description

Pipe a list from a SQL query for the bulk case. The runner is idempotent at the row level — when wired into a cron, it reads description IS NULL filters rather than a static SKU list.

6. Provider abstraction — swap OpenAI for Anthropic in one line

The CLI command does not know it is calling OpenAI. It depends on LlmProviderInterface; di.xml resolves the interface to OpenAiClient by default.

The interface

<?php
declare(strict_types=1);

namespace Panth\AiAssist\Api;

use Panth\AiAssist\Api\Data\PromptTemplateInterface;

interface LlmProviderInterface
{
    public function complete(PromptTemplateInterface $template, array $variables): string;
}

The default preference

<?xml version="1.0"?>
<config xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance"
        xsi:noNamespaceSchemaLocation="urn:magento:framework:ObjectManager/etc/config.xsd">
    <preference for="Panth\AiAssist\Api\LlmProviderInterface"
                type="Panth\AiAssist\Service\OpenAiClient"/>
</config>

The Anthropic swap

Drop a one-line override in app/etc/di.xml to switch every LlmProviderInterface consumer to Claude.

<preference for="Panth\AiAssist\Api\LlmProviderInterface"
            type="Panth\AiAssist\Service\AnthropicClient"/>

Provider trade-offs

Pricing pinned to published rates — confirm against openai.com/pricing^[2] and anthropic.com/pricing^[3] before quoting. Rate limits assume Tier-1 paid accounts; free-tier limits are ~10x tighter and not production-viable.

Pin the model version — never gpt-4o, always gpt-4o-2024-11-20. Floating versions change brand voice between Monday and Friday without warning, and your bulk-written product descriptions stop matching your style guide.

7. Security boundary — API keys live encrypted, never in markdown

The single highest-priority boundary on any OpenAI + Magento integration is the API key. Get this wrong and a leaked key racks up tens of thousands of dollars on someone else's account inside a weekend.

Three rules we apply on every project

1. Never put API keys in any markdown file. Not README.md, not CLAUDE.md, not NOTES.md. Markdown files are version-controlled and grep-scanned by every leaked-credential bot on the planet.
2. Keys live in app/etc/env.php encrypted by Magento's EncryptorInterface. The admin field uses backend_model="Magento\Config\Model\Config\Backend\Encrypted"; Magento writes ciphertext into system.default.panth_aiassist.openai.api_key. The decryption key is the crypt/key from the same file. Neither belongs in git.^[4]
3. Rotate every 90 days, one key per environment. Dev, staging, and production each get their own OpenAI key. A leak on dev does not nuke production.

The admin field definition

<field id="api_key" translate="label" type="obscure" sortOrder="10" showInDefault="1" showInWebsite="0" showInStore="0">
    <label>OpenAI API key</label>
    <backend_model>Magento\Config\Model\Config\Backend\Encrypted</backend_model>
    <comment>Stored encrypted in app/etc/env.php. Rotate every 90 days.</comment>
</field>

The decryption call site

$encrypted = (string)$this->scopeConfig->getValue('panth_aiassist/openai/api_key');
$apiKey = $this->encryptor->decrypt($encrypted);

Decryption happens in exactly one place — OpenAiClient::getApiKey(). No logger sees the plaintext. No debug var-dump serializes it. The encrypted ciphertext can be checked into a config-management tool; the plaintext only exists in memory during a single HTTP call.

Prompt-injection isolation

Customer-controlled data flows through placeholders into the prompt body. Wrap every customer-sourced placeholder in a delimited block — <customer_input>...</customer_input> — before substitution. The system prompt instructs the model to treat the delimited block as untrusted data and to never follow instructions inside it. An output filter scans the response for tool-call-shaped strings before any downstream system sees it.

Where this fits in a Hyvä + Magewire stack

The module is back-office only by default — admin grid, CLI runner, and call log all run inside the admin area or CLI. To expose a template to a customer-facing widget, wire a Hyvä block that calls LlmProviderInterface with a capped max_tokens and a strict template-code allowlist. Most Panth_AiAssist installs ship in 24–36 hours from spec to deployed.

Related reading

• Integrate ChatGPT with Magento 2 — 4 real patterns
• Magento GraphQL custom resolver — a complete walkthrough
• Magento 2 development service
